DC9DZ: Project Tsunami 100K – Power Amplifier (PA) using two 4CX15000A Frequency bands all HF amateur bands 1.8 MHz to 29.7 MHz Power supply 3 power supply transformers 35000 VA, 4800 VA & 3 VA Plate voltage 12000 V at full output power Screen voltage 1500 V stabilized Grid voltage – 385 V +/- 30…
DetailsFeatures: Easy operation. The plate-load True Resistance Indicator (TRI) is an ACOM innovation that provides quick and precise tuning, typically in less than 10 seconds. The auto-operate function will return the amplifier to the OPERATE mode automatically after each protection trip, saving time and avoiding manual switching. No tuner needed. No external antenna tuner is…
DetailsRF Linear amplifier coverd 1.8-30MHz amateur bands , using Chinese FU728F ceramic tetrodes working at Class AB1 Driving power:30-40W output:2000W ; Driving power :60-70W output:2600W ( no recommend) . 3rd Order: -34dbc Protection:exceed anode temerture;exceed current(screen and anode);over drive; SWR. Heavy duty band switch and heavy duty HV transformer, independent filament transformer. Net weight :38kg,…
DetailsFeatures: The ACOM3x2000A is a HF power splitter / combiner which is a passive device designed to sum the outputs of three HF linear amplifiers into a common load while the amplifiers are driven by a single exciter. There is no difference from the operation of a three times more powerful single amplifier. For proper…
DetailsFeatures: The ACOM 2000A Automatic HF Linear Amplifier is the world’s most advanced HF amplifier designed for amateur use. The ACOM 2000A is the first amateur HF amplifier to include both fully automatic tuning and sophisticated digital control capabilities. This revolutionary new amplifier delivers maximum legal power in all modes and operates on all HF…
Details
