DL435-30 is a state-of-the-art, high performance embedded OFDM radio transceiver specially optimized for the frequency band 420 MHz ~ 450 MHz (70 cm). It features high data throughput with up to 600 mW Tx power, better Rx sensitivity and high noise immunity. DL435-30 features Doodle Labs’ proprietary PrismTM hybrid heterodyne technology with advanced filtering and noise reduction techniques for high interference immunity and long range applications. The DL435-30 has demonstrated the ability to provide high throughput even in extremely noisy environments. The rugged construction of DL435-30 makes it ideal for deploying in carrier class equipment.
DLM108 Front_Edited
DL435-30 maintains distortion free signal at higher modulation rates and high power to maintain low packet errors and maximize data throughput. The design uses highly linear power amplifiers to deliver maximum power even at 64 QAM radio modulations while maintaining low distortion EVM (Error Vector Magnitude). With better Rx sensitivity and high SNR, DL435-30 is specially designed to deliver best performance in long-range applications. The Industrial/Military grade design & enhanced resilience to RF surges & ESD makes it ideal for deploying in harsh environments.
Key Features:
Best-in-class OFDM broadband radio technology ensures high throughput, spectral efficiency, advanced RF interference mitigation and resistance to multi-path delays for Near Line of Sight (NrLOS) performance.
Doodle Labs’ proprietary PrismTM hybrid heterodyne technology with advanced filtering and noise reduction techniques to achieve high Interference Immunity.
Operation in the 420 – 450 MHz UHF frequency (70 cm) band for Amateur radio services in the ITU’s regions 1, 2 and 3.
Up to 15 Mbps data throughput.
Software configurable high Tx power up to +28 dBm (600 mW) for long-range coverage.
High desensitization capability for out of band interfering signals.
Distortion free signal (low EVM) to maintain lowest packet errors to maximize data throughput at higher data modulation.
128 bit AES encryption for over the air data security
Supports software configurable 5 and 10 MHz Channel Bandwidth to maximize spectrum efficiency.
Traffic prioritization queues for video, voice and data applications.
mini-PCI host interface
Supported by open source MadWiFi Linux kernel drivers
Proven compatibility with dd-wrt and many other 3rd party Wireless Router Operating Systems
Military grade design ensures durability in harsh operating environments
Two MMCX connectors provide flexibility in system design for antenna diversity or Internal/external antenna selection options
